Classification from Wells (1956), as modified by Stolarski (1995, 1996). The superfamily marked with a cross ( ) occurs only in the fossil record, whereas the other two superfamilies contain both fossil and Recent taxa.
Containing group: Scleractinia


The caryophylliines are known from the early Jurassic (180 million years ago) to the Recent, and occur in most marine environments to a depth of 3200 m. They are an extremely diverse group, consisting of 91 living genera and 457 living species (Cairns et al., 1999). Although some species form large colonies that may contribute to both shallow-water and deep-water reef/bank structure, most members of this suborder are small (less than 30 mm) and inconspicuous, occurring in cryptic shallow-water environments or in cold (as low as -1°C), dark, deep waters. Although several other scleractinian families occur in deep water (e.g., Dendrophylliidae, Micrabaciidae, Fungiacyathidae), the caryophylliines have been the most successful in exploiting the deep-sea realm. Because many occur below the euphotic zone or cryptically in shallow water, most species are azooxanthellate (do not contain symbiotic unicellular dinoflagellates) and therefore rarely attain a large size.


Suborders within the Scleractinia are distinguished by the structure of their septa. The septa of the caryophylliines are lamellar, composed of one fan system of simple, very small trabeculae (minitrabeculate), resulting in a smooth or nearly smooth inner margin (Vaughan and Wells, 1943; Wells, 1956).

The superfamilies within this suborder are characterized by the structure of their walls (theca). The most primitive of the three superfamilies, the Volzeioidea, have an exclusively epithecate wall (see Stolarski, 1995, 1996); that of the Flabelloidea is marginothecate; and that of the Caryophyllioidea is septo- or parathecate. In the latter two cases a nontrabecular deposit of epitheca or textura may be added to the exterior of the corallum (Stolarski, 1995).

Discussion of Phylogenetic Relationships

No phylogenetic analysis has been performed on the suprageneric taxa of the Caryophylliina; however, Stolarski (1995, 1996), Romano and Palumbi (1996), and Romano and Cairns (2000) are currently investigating and reassessing the higher level relationships in the suborder by using characteristics of the corallum microstructure and DNA sequencing, respectively (see Scleractinia branch page). Roniewicz and Morycowa (1993) and Veron (1995: 110) should also be consulted for more recent, non-cladistic evolutionary trees of all scleractinian families.


The higher classification of the suborder Caryophylliina is in a state of flux as more information is being discovered through microstructural and molecular analyses. Stolarski (1996, 2000) has best summarized the conflicting morphological characters, which resulted in two fairly different classification hypotheses for the superfamilies and families of the caryophylliines, which are both different from the classification presented here. In general, we agree with he work of Stolarski (2000), and, in general, adopt his "Hypothesis A", but with some modifications that reflect a more traditional view. Thus, we continue to recognize the superfamily Flabelloidea and place the Guyniidae in that superfamily, but we do accept his new family Stenocyathidae, which he places in the superfamily Caryophyllioidea, and his new family Schizocyathidae, which he places in the superfamily Volzeioidea.


Cairns S. D., B. W. Hoeksema, and J. van der Land. 1999. Appendix: List of Extant Stony Corals. Attol Research Bulletin, 459:13-46.

Romano, S. L. and S. R. Palumbi. 1996. Evolution of scleractinian corals inferred from molecular systematics. Science, 271: 640-642.

Romano, S. L. and S. D. Cairns. in press. Molecular Phylogenetic Hypotheses from the Evolution of Scleractinian Corals. Bulletin of Marine Science.

Roniewicz, E. and E. Morycowa. 1993. Evolution of the Scleractinia in the light of microstructural data. Courier Forschungsinstitut Senkenberg, 164: 233-240.

Stolarski, J. 1995. Ontogenetic development of the thecal structures in caryophylliine scleractinian corals. Acta Palaeontologica Polonica, 40: 19-44.

Stolarski, J. 1996. Gardineria -- a scleractinian living fossil. Acta Palaeontologica Polonica, 41: 339-367.

Stolarski, J. 2000. Origin and phylogeny of Guyniidae (Scleractinia) in the light of microstructural data. Lethaia, 33: 13-38.

Vaughan, T. W., and J. W. Wells. 1943. Revision of the suborders, families, and genera of the Scleractinia. Geological Society of America, Special Papers, 44: 363 pp.

Veron, J. E. N. 1995. Corals in Space and Time. 321 pp. UNSW Press, Sydney.

Wells, J. W. 1956. Scleractinia. Pp. F328-F444 In: Moore, R. C (editor) Treatise on Invertebrate Paleontology, Part F: Coelenterata. University of Kansas Press, Lawrence.

Title Illustrations
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Scientific Name Deltocyathus rotulus
Location off Sabah, Borneo (depth 871 m)
Specimen Condition Dead Specimen
Body Part skeleton
View Calicular view
Size Diameter of calice 30 mm
Image Use creative commons This media file is licensed under the Creative Commons Attribution-NonCommercial License - Version 3.0.
Copyright © 2002
Scientific Name Flabellum deludens
Location Philippines (depth 289 m)
Specimen Condition Dead Specimen
Body Part skeleton
View side view
Size Width of corallum 45 mm
Image Use creative commons This media file is licensed under the Creative Commons Attribution-NonCommercial License - Version 3.0.
Copyright © 2002
