Under Construction

Abraliopsis sp. E

Richard E. Young
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Containing group: Abraliopsis (Micrabralia)

Introduction

Abraliopsis sp. E is known from a single small (21 mm ML), but mature, male taken in the Central Equatorial Pacific at 7°15'N, 149°54'W.

Brief diagnosis:

An Abraliopsis (Micrabralia) ...

Characteristics

  1. Arms
    1. All arms lack tubercules; left ventral arm without special modifications.
    2. Arms I-III with well developed trabeculate protective membranes, with slender trabeculae, only on ventral margins.
    3. Very low protective membranes on arms IV (excluding hectocotylization) with short trabeculae projecting freely from membranes especially on both margins of left arm IV.
    4. Arms I-III with 18-20 hooks and two series of small suckers at extreme distal end of arms. Left arm IV with 24 hooks and no suckers.
    5. Hooks of arms IV smaller than those of other arms.
    6. Hectocotylus (right arm IV) with long, wide ventral flap, and shorter, wide offset dorsal flap. Low membrane extends from distal end of ventral flap to base of arm tip bearing large, black photophores.
    7. Hectocotylus with 18 hooks; distal-most hook at proximal end of dorsal flap; suckers absent. Left arm IV with 24 hooks; distal-most hook very near terminal large photophores.
    8. Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Arms III and IV of Abraliopsis sp. E, mature male, 21 mm ML, central Equatorial Pacific. Left - Oral views of left arms III and IV. Middle - Dorso-oral view of right arm IV (hectocotylus). Right - Ventral view of the distal portion of right arm IV. Note the large trabecula at the proximal end of the ventral flap. Photographs by R. Young.

  2. Tentacles
    1. Largest hooks of ventral series of manus about 2.5 times height of dorsal counterparts.
    2. Manus with 6 or 7 hooks.
    3. Narrow, short keel restricted to dactylus; narrow carpal flap.
    4. Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure.Tentacular clubs of Abraliopsis sp. E. Left - Oral view of right club showing the carpal flap and keel. Right - Dorsal (left) and Ventral (right) views of left club showing the relative sizes of the hooks. Photographs by R. Young.

  3. head
    1. Occipital crest with occipital folds 3 and 4 joined posteriorly by distinct crescent-shaped ridge.

  4. Fins
    1. Fins large, nearly 70 % of ML.


  5. Photophores
    1. Ocular photophores: 5 photophores with end members about 2X larger than adjacent photophores.
    2. Integumental photophores: 3 series on ventral head, 6 on ventral mantle.
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Ventral view of the mantle and funnel of Abraliopsis sp. E. Left - Photograph of the preserved squid. Middle - Outline drawing from photograph with all integumental photophores represented by colored dots.  Red dots - Complex photophores. Blue dots - Non-complex photophores. Images by R. Young.

      More information on integumental photophores can be found here.

  6. Viscera
    1. Mantle cavity
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Ventral view of the mantle cavity of Abraliopsis sp. E, showing the penis and Needham's sac full of spermatophores. Photograph by R. Young.

    2. Spermatophore
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. View of the spermatophore (6 mm long) of Abraliopsis sp. E with enlarged insert of oral end, mature male, 21 mm ML, central tropical  Pacific. Photograph by R. Young.

  7. Measurements (mm) and counts.
      R/L
    Sex
    Male, mature
    Mantle length
    21
    Head width index
    42.9
    Fin Length index
    68
    Fin width index
    100
    Arm Length index (R/L):
    I
    58.6/60.5
    II
    66.7/69.5
    III
    66.7/67.6
    IV
    83.3/81
    No. arm hooks (R/L):
    I
    19/19
    II
    -/20
    III
    19/18
    IV
    18/24
    Club length index (R/L)
    24.8/26.7
    Club hooks (D/V)(R:L)
    3/3; 3/3
    Carpal suckers (R/L)
    5/5

Comments.

Superficially Abraliopsis sp. E looks like a member of the subgenus Pfefferiteuthis; however it lacks the highly modified arms IV of that group.  It is easily separated from other members subgenus Micrabralia by the characters listed in the "Brief diagnosis" above.

See Abraliopsis (Micrabralia) page for comparisons among all species of the subgenus.

Title Illustrations
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Scientific Name Abraliopsis sp. E
Location Central Equatorial Pacific at 715'N, 14954'W
Specimen Condition Preserved
Sex Male
Life Cycle Stage Mature
View Ventral
Size 21 mm ML
Collector Thomas A. Clarke
Image Use creative commons This media file is licensed under the Creative Commons Attribution License - Version 3.0.
Copyright ©
About This Page


University of Hawaii, Honolulu, HI, USA

Correspondence regarding this page should be directed to Richard E. Young at

Page: Tree of Life Abraliopsis sp. E. Authored by Richard E. Young. The TEXT of this page is licensed under the Creative Commons Attribution-NonCommercial License - Version 3.0. Note that images and other media featured on this page are each governed by their own license, and they may or may not be available for reuse. Click on an image or a media link to access the media data window, which provides the relevant licensing information. For the general terms and conditions of ToL material reuse and redistribution, please see the Tree of Life Copyright Policies.

Citing this page:

Young, Richard E. 2013. Abraliopsis sp. E. Version 03 November 2013 (under construction). http://tolweb.org/Abraliopsis_sp._E/144396/2013.11.03 in The Tree of Life Web Project, http://tolweb.org/
