Onychoteuthis Lichtenstein, 1818

K.S.R. Bolstad, Michael Vecchione, Richard E. Young, and Kotaro Tsuchiya
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
This genus has contained four generally recognized species until recently; present accounts place the number at ~10, and more undescribed species probably exist.
taxon links [up-->]Onychoteuthis lacrima [up-->]Onychoteuthis horstkottei [up-->]Onychoteuthis prolata [up-->]Onychoteuthis meridiopacifica [up-->]Onychoteuthis banksii [up-->]Onychoteuthis bergii [up-->]Onychoteuthis aequimanus [up-->]Onychoteuthis borealijaponica [up-->]Onychoteuthis mollis [up-->]Onychoteuthis compacta [down<--]Onychoteuthidae Interpreting the tree
close box

This tree diagram shows the relationships between several groups of organisms.

The root of the current tree connects the organisms featured in this tree to their containing group and the rest of the Tree of Life. The basal branching point in the tree represents the ancestor of the other groups in the tree. This ancestor diversified over time into several descendent subgroups, which are represented as internal nodes and terminal taxa to the right.

example of a tree diagram

You can click on the root to travel down the Tree of Life all the way to the root of all Life, and you can click on the names of descendent subgroups to travel up the Tree of Life all the way to individual species.

For more information on ToL tree formatting, please see Interpreting the Tree or Classification. To learn more about phylogenetic trees, please visit our Phylogenetic Biology pages.

close box
Containing group: Onychoteuthidae

Introduction

Members of the genus are mostly small to medium sized squids of under 20 cm in mantle length as adults. The largest, however (O. borealijaponica) reaches a size of 350 mm ML (Kubodera et al. 1998). Species are found mostly in tropical and subtropical waters throughout the world's oceans although they are also common in high latitudes of the North Pacific, where O. borealijaponica reaches subarctic waters. One of the diagnostic features of Onychoteuthis species is the presence of one bilobed photophore (or two smaller, separate photophores, in O. horstkottei) on the ventral surface of each eyeball as seen in the photograph below (right). Another diagnostic feature is the presence of two photophores (arrows) on the viscera, as can barely be seen through the mantle in the photograph below (left).

Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Figure. Ventral views of Onychoteuthis sp. showing photophores. Left - Arrows indicate visceral photophores (ocular photophores also visible), juvenile. Right - Ocular photophores of a different squid. Both squid from Hawaii waters. Photographs by R. Young.

Species of Onychoteuthis are commonly seen in surface waters at night and are often collected by dipnet at nightlight stations. Only young squid are normally captured in standard midwater trawls; apparently older squids avoid the trawls. One non-standard method of collection results from individuals being able to leap high out of the water and, sometimes, land on the deck of a ship.  The type specimens of O. bergii were collected in this way: 'Our two specimens came to us as part of the rich inheritance of specimens from our brave Bergius, who died in the Cape of Good Hope in January of this year of tuberculosis, the victim of his own tireless efforts at collecting and observing plants and animals. His journal from the voyage reveals that these specimens flew on board the ship one night. One was found the following morning on the foredeck, the other in the crow’s nest, thirty feet above the sea surface, more evidence to support Aristotle’s remarks on their power of flight. The very elastic lateral flaps or fins may be of particular use in this respect. This occurred in May, 1816, approximately 100 miles west of the Cape. I have heard from other seafarers that other similar animals were collected in this way at about the same time.' (Translated from Lichtenstein 1818.)

Brief diagnosis:

An onychoteuthid ...

Characteristics

  1. Arms
    1. Arm suckers with distal, fleshy thickening (see arrows in photograph below) in most species. This delicate thickening or knob is not obvious on all suckers and when present it is easily damaged during capture.

    2. Protective membranes low and with trabeculae fused to sucker base and not clearly seen as separate entities (see photograph below).
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Lateral views of preserved arm suckers of Onychoteuthis sp. Photographs by R. Young.

  2. Tentacular club
    1. Marginal suckers absent in subadults except for O. meridiopacifica (several marginal suckers present).
    2. Distal suckers on club restricted to terminal pad.
    3. Dorsal hook-series with hooks that are small in size in mid-series (see arrows on drawing below) with larger hooks proximally and distally.
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Oral view of tentacular club of Onychoteuthis "banksii." Drawing modified from Naef, 1921/23.

  3. Head
    1. 8-13 occipital folds present on each side of head. Arrows in the photograph below indicate the ventral 7 occipital folds. Additional very small dorsal folds are out of focus and not visible in the picture. The olfactory organ is at the posterodorsal end of occipital fold II.
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Lateral view of head showing occipital folds of preserved Onychoteuthis sp. Photograph by R. Young.

  4. Funnel groove
    1. Funnel groove with distinct ridges along margin; margins convex near anterior, pointed end of groove (squid must be in good condition to see this feature).
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Ventral view showing funnel groove of preserved Onychoteuthis sp. Photograph by R. Young.

  5. Mantle
    1. Mantle skin smooth.

  6. Photophores
    1. Large organ present ventrally on each eye (see Introduction).
    2. Two organs present on intestine.
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Ventral view of intestinal photophores of Onychoteuthis sp. Drawing modified from Young, 1972.

  7. Gladius
    1. The dorsal mantle musculature and fins are bisected by the gladius. (The resulting line down dorsal midline generally is visible through the skin - see title drawing).
    2. Rostrum thin (i.e., laterally compressed) and pointed (except in O. meridiopacifica).

Species comparisons

 (Modified from Bolstad 2010)

Species
Visceral photophores Ocular photophore(s) on each eye Club length (% ML) &  hooks Spike on distal-most ventral hooks Habitat
O. bergii Large, circular, posterior > anterior One ~25%21–23 Present by ML 92 mm Southern Atlantic, Indian Oceans
O. banksii Large, circular, posterior >> anterior One ~27%20–23 Absent Central & North Atlantic, Gulf of Mexico
O. aequimanus Large, circular, posterior > anterior One ~28%19–23 May be present from ML 90 mm Pacific Ocean south of 30°N
O. mollis Large, circular, posterior >> anterior One Unknown Unknown Mediterranean (one specimen known)
O. compacta Large, circular, posterior >> anterior One ~21%20–23 Present by ML 60 mm Central Pacific, and 0–40°N in western Atlantic
O. borealijaponica Slender, tear-drop-shaped One ~27%23–27 Present (small) North Pacific
O. meridiopacifica Minute, circular, posterior > anterior One ~ 19%15–19 Absent Indian and Southwest Pacific Oceans
O. lacrima Posterior tear-drop-shaped, anterior circular, minute One ~ 29%20–24 Present by ML 50 mm North-central Pacific
O. prolata Large, circular, posterior >> anterior One ~36%20–23 Absent Worldwide in temperate and tropical oceans
O. horstkottei Large, circular, posterior and anterior ~subequal Two ~24%20–22 Present by ML 54 mm Eastern equatorial Pacific

Behavior

Paralarvae of Onychoteuthis, like the paralarvae of many other squid, have the ability to withdraw their head and arms into their mantle cavity. This behavior is, presumably, defensive.

Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Figure. Ventral views of a paralarva of O. compacta, head extended and retracted, off Hawaii. Photographs.

Life History

Most paralarval Onychoteuthis are easily recognized by the pointed rostrum on the gladius. If the fins are damaged, the rostrum projects well beyond the fins (see photographs of the paralarvae in the previous section). The photograph on the left (ventral view, posterior end of a paralarva) shows the rostrum barely emerging and the photograph on the right (side view, posterior end of a paralarva) shows the rostrum just reaching to the edge of the fins. Even if the rostrum is not protruding due to damage, it still can be easily seen.

Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Figure. Ventral and side views of posterior ends of Onychoteuthis sp. paralarva, off Hawaii. Photographs by R. Young.

The adult female looses its tentacles apparently near the time of spawning. Spent females which are very flaccid were originally described as belonging to the genus Chaunoteuthis. In the photograph below the upper white arrow points to a scar that parallels much of the sissors cut through the mantle. This scar was apparently made by the male when mating. The lower arrow points to one of about 9 spermatangia embedded in the mantle muscle that apparently entered at the scar.

Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Figure. Left - Ventral view, female "Chaunoteuthis stage" of Onychoteuthis sp. , a mated and presumably (i.e. damage prevented assessment) spent female, preserved, 155 mm ML. Photograph by R. Young. Right - Dorsal view of "Chaunoteuthis mollis". Drawing from Pfeffer (1912).

Distribution

Species of Onychoteuthis are absent from the Arctic, upper boreal Atlantic, subantarctic and Antarctic waters, but occur in all other oceans (Nesis, 1982/87).

References

Bolstad, K.S.R. 2010. Systematics of the Onychoteuthidae Gray, 1847 (Cephalopoda: Oegopsida). Zootaxa, 2696: 186pp.

Lichtenstein, H.C. 1818. Onychoteuthis, Sepien mit Krallen. Isis, 1818: 1591–1592.

Kubodera, T., U. Piakowski, T. Okutani and M. R. Clarke. 1998. Taxonomy and zoogeography of the family Onychoteuthidae. Smiths. Contr. to Zoology, No. 585: 277-291.

Nesis, K. N. 1982/87. Abridged key to the cephalopod mollusks of the world's ocean. 385+ii pp. Light and Food Industry Publishing House, Moscow. (In Russian.). Translated into English by B. S. Levitov, ed. by L. A. Burgess (1987), Cephalopods of the world. T. F. H. Publications, Neptune City, NJ, 351pp.

Young, R. E. 1972. The systematics and areal distribution of pelagic cephalopods from the seas off Southern California. Smithson. Contr. Zool., 97: 1-159.

Title Illustrations
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Scientific Name Onychoteuthis borealijaponica
Location Monterey Bay Canyon, Northeast Pacific at 36.7°N, 122.1°W.
Comments Image courtesy of the Monterey Bay Aquarium Research Institute (MBARI). You must obtain permission from MBARI to use this photo; please contact pressroom@mbari.org for further information
Acknowledgements Susan Von Thun, photo editing, MBARI
Specimen Condition Live Specimen
View Side
Copyright © 2011 MBARI
Scientific Name Onychoteuthis "banksii"
Reference Pfeffer, G. 1912. Die Cephalopoden der Plankton-Expedition. Zugleich eine Monographische Übersicht der Oegopsiden Cephalopoden. Ergebniss der Plankton- Expedition der Humboldt-Stiftung, 2:1-815.
View Dorsal
