Ancistroteuthis lichtensteinii: Description Continued

Click on an image to view larger version & data in a new window

Figure. Dorsal view of A. lichtensteini, type B, 145 mm ML, preserved, 21°35'S, 02°00'W, USNM specimen. Photograph by R. Young.

1. Tentacles
1. Terminal pad of club with 16-17 (Kubodera, et al., 1998) or 15-18 (Pfeffer, 1912) small suckers.
2. Club with double series of hooks; marginal suckers absent.
3. Club with 19-24 hooks (Pfeffer, 1912), 20-21 hooks (Kubodera, et al., 1998).
4. Carpal pad with 9-12 suckers (Pfeffer, 1912), 9-10 suckers (Kubodera, et al., 1998).
5. Club length 30-40% of ML (Pfeffer, 1912), 30% of ML (Kubodera, et al., 1998).


Click on an image to view larger version & data in a new window




Figure. Views of the club of A. lichtensteini type A. Top - Dorsal view, 110 mm ML, USNM 294756. Photograph by R. Young. Bottom - Oral view, 145 mm ML, Mediterranean Sea. Drawing from Pfeffer, 1912.

Scanning electron micrographs of the club hooks can be found here.

2. Arms
1. Length 75% (Naef, 1921-23) or 40-53% (Kubodera, et al., 1998) or 67-75% (Pfeffer, 1912) of the ML.
2. Arms subequal but slight differences give the formula 2>3>4>1 (Naef, 1921-23).

3. Head
1. Funnel groove with V-shape (see title photograph on first page).
2. Beaks
1. Beaks are very different from those of Onychoteuthis. The upper jaw has a long, slender rostrum; the jaw angle is rounded and obtuse. The lower beak has an accessory tooth (not visible in side view) and a lateral wall ridge (Naef, 1921-23).


Click on an image to view larger version & data in a new window



Figure. Upper (left) and lower (right) beaks, A. lichtensteini, URL ca. 3 mm. Drawing from Naef, 1921-23.

3. Radula
1. The radula has a tricuspid rhachidian and a distinctly bicuspid lateral tooth 1.


Click on an image to view larger version & data in a new window



Figure. Radula, A. lichtensteini. Drawing modified from Naef, 1921-23.

4. Mantle
1. Posteroventral mantle keel present.

5. Fins
   1. Fins sagittate, attenuated posteriorly.
   2. Length 60-68% of ML (Pfeffer, 1912).
   3. Width 48-68% of ML (Pfeffer, 1912).


   Click on an image to view larger version & data in a new window



   Figure. Left - Dorsal view of fins, A. lichtensteini type A, 110 mm ML, 20°27'N, 21°58'W, USNM 294756. Photograph by R. Young. Right - Dorsal view of fins, A. lichtensteini type B, 145 mm ML, preserved, 21°35'S, 02°00'W, USNM specimen. The photographs show the variation in the shape of the fins between two Atlantic Ocean squid. The squid on the right with the peculiar rhomboidal fin is the squid pictured in the title photograph of this page. Photograph by R. Young.

6. Gladius
   1. Gladius not visible on dorsal side of mantle (i.e., mantle completely surrounds gladius).
   2. Thick midrib of rhachis present only in posterior half of gladius.
   3. Rostrum long (14-15% of ML) and laterally conpressed (Pfeffer, 1912), but more massive, less firm and more cartilagenous than in Onychoteuthis (Naef, 1921-23).
   4. Vanes of gladius very narrow or absent.


      Click on an image to view larger version & data in a new window



      Figure. Top - Ventral view of the gladius A. lichtensteini. Bottom - Enlarged side view of posterior end of same gladius , 165 mm ML, Mediterranean Sea. Drawing from Pfeffer, 1912.

References

Kubodera, T., U. Piakowski, T. Okutani and M. R. Clarke (1998). Taxonomy and zoogeography of the family Onychoteuthidae (Cephalopoda: Oegopsida). Smiths. Contr. to Zoology, no. 586: 277-291.

Naef, A. 1921-23. Cephalopoda. Fauna und Flora des Golfes von Neapel. Monograph, no. 35. English translation: A. Mercado (1972). Israel Program for Scientific Translations Ltd., Jerusalem, Israel. 863pp., IPST Cat. No. 5110/1,2.

Pfeffer, G. 1912. Die Cephalopoden der Plankton-Expedition. Ergebnisse der Plankton-Expedition der Humboldt-Stiftung. 2: 1-815.
