Nematolampas venezuelensis: Description continued

1. Arms
1. Arm formula: III>II>IV>I.
2. Arms III much more robust than arms II.
3. Trabeculate protective membranes present on suckered portions of all arms.
4. Arm sucker (midportion of arms) rings with 9-12 sharp teeth distally, bluntly pointed teeth proximally.

Click on an image to view larger version & data in a new window


Figure. N. venezuelensis, holotype. Left - Lateral view of arm crown showing the relative thickness of arms II and III. Circular photophores can be seen on the base of arm III. Photograph by R. Young. Right - Large sucker from basal portion of arm IV. Drawing from Arocha (2003).

2. Tentacles
1. Tentacular club with suckers on carpus in 4 series, suckers on dactylus and manus small and in 4 series.


3. Head
1. Beaks. Lower beak with thick lateral wall ridge.

Click on an image to view larger version & data in a new window


Figure. Side views of upper (left) and lower (right) beaks of N. venezuelensis, paratype, 69.7 mm ML. Drawings from Arocha (2003).

2. Radula. Radula homodont, marginal plates absent.

Click on an image to view larger version & data in a new window


Figure. Radula (one side) of N. venezuelensis, paratype, 69.7 mm ML. Drawing modified from Arocha (2003).

4. Fins and tail
1. Fins sagittate with short tail.


5. Photophores
1. Arm II with 9 photophores in proximal third.
2. Arm III with 19 photophores in proximal two thirds.
3. Tentacle with 2 photophores.
4. Head with 4 pairs of photophores: One member at base of arm III, one at anterior and posterior edges of eyelid, one on dorsolateral head at posterior margin.
5. Eye with 5 photophores in ventral series; middle photophore largest.

Click on an image to view larger version & data in a new window


Figure. N. venezuelensis, holotype. Left - Dorsal view of head, arms and tentacle showing photophore (blue) arrangement. Right - Lateral view of eyeball showing ocular photophores. Drawings modified from Arocha (2003).

6. Dorsal mantle anterior to fins with 5 pairs of photophores.
7. Dorsal fin with 3 pairs of photophores.
8. Dorsal surface near base of tail with large embedded photophore in midline beneath a dorsal window and surrounded by three small photophores at the periphery of the window.

Click on an image to view larger version & data in a new window


Figure. Views near the tail base in N. venezuelensis, holotype. Left - Dorsal view showing the window overlying the embedded photophore. Only the anterior of the three photophores surrounding the window can be clearly seen in the photograph. Right - Ventral view showing the embedded photophore which was apparently cut when the gladius was removed. Photographs by R. Young.

9. Dorsal tail with a series of five photophores in midline, termining at apex of tail.
10. Ventral surface of mantle with 6 pairs of photophores near or along lateral margins, one unpaired midline photophore near base of tail (ventral to large dorsal photophore).
11. Tail with a pair of lateral photophores (in addition to the dorsal series).
12. Ventral viscera (within mantle cavity) with a pair of anal photophores, 3 abdominal photophores, 2 elongate gill photophores and 3 posteroabdominal photophores.
13. All visceral photophores, except anal photophores, connected by strips of tissue (see figure).

Click on an image to view larger version & data in a new window


Figure. Mantle, fins and tail of N. venezuelensis showing arrangement of photophores (blue), holotype. Left - Dorsal view. Middle - Ventral view. Right - Ventral view of visceral photophores within the mantle cavity. Drawings modified from Arocha (2003).

6. Gladius

Click on an image to view larger version & data in a new window


Figure. Gladius of N. venezuelensis, holotype. Top - Cross-sections. Middle - Dorsal view. Bottom - Side view. Drawings from Arocha (2003).

7. Viscera
1. Male secondary reproductive structures unpaired (i.e. single male genitalia).


8. Measurements

   Mantle length	58.2	65.0	69.7	87.5
   Sex	Immat. male	Immat. male	Immat. male	Immat. male
   Status	Paratype	Paratype	Paratype	Holotype
   Respository	UMML31.3144	UMML31.3144	UMML31.3143	USNM 817596
   Mantle width index	35.4	37.2	37.3	26.0
   Head length index	23.2	18.9	18.2	16.8
   Head width index	22.9	22.0	18.5	23.7
   Eye diameter index	18.9	20.0	21.5	18.3
   Fin length index	36.4	38.8	33.9	36.3
   Fin width index	96.6	79.7	87.5	74.7
   Arm I, length index	59.3	41.5	41.6	30.3
   Arm II, length index	119.8	80.3	81.8	88+
   Arm III, length index	191.9	111+	172.9	171.4
   Arm IV, length index	49.7	45.9	42.6	38.9
   Tentacle length index	--	--	--	125.7
   Club length index	--	--	--	22.4
   Gladius length index	96.4	86.2	84.7	74.3
   Gladius width index	11.5	7.7	7.9	4.9
   Rhachis width index	6.2	5.1	4.6	3.9

   UMML - University of Miami Marine Laboratory
   NMNH - United States National Museum of Natural History
   Index - Measurement as a percent of the mantle length

Comments

The above description is from Arocha (2003). The number of photophores in the drawing of the arms differs slightly from the number mentioned in the text.

References

Arocha, F. 2003. A new species of Nematolampas (cephalopoda: Oegopsida) from the Western Central Atlantic with an overview of the family Lycoteuthidae. Bull Mar. Sci., 72: 941-953.
